Access-ER
High performance
RFID handheld
terminal
Public Transportation | Ticketing | Access Control | Asset Tracking | Logistics
High performance RFID handheld terminal
For the current Coppernic Products, click here.
Rugged, lightweight mobile device with Enhanced Read RFID capability
The Access-ER combines the attributes of a rugged Android mobile device with several high performance RFID reader options, to create a fit-for-purpose tool for multiple applications.
Coppernic’s ACCESS-ER
handheld terminals
in daily use on
Marseilles public transport!
The Access-ER extends the family of Access terminals into new applications for
Public Transport ticketing,
Smart Asset Tracking and mobile solutions for Physical Access Control systems.
MULTIPLE
Keypoints
CHOICE
PERFORMANCE
RUGGED
Fully integrated, one-piece rugged solution.
LIGHTWEIGHT
Easy to handle with one hand.
TECHNICAL
Specifications
| MODULES | • HF ASK Module (PARAGON ID UCM108) • HF ASK RCTIF | CEN/TS Module (PARAGON ID UCM108) • HF | LF | BT HID-CK Module (OMNIKEY 5127 CK-Mini) |
| CAMERA | Front camera: 5MP | Rear camera: 13MP Autofocus |
| SECURE ELEMENT | P73N2MP (NFC IC) | SIM/USIM socket (SWP IF with NFC IC + ISO7816 IF with CPU) |
| BARCODE READER (OPTIONAL) | Honeywell N6603 2D Imager |
OPERATING SYSTEM | Android 10 AOSP |
| PROCESSOR | Octa Core @ 2.2 GHz | Qualcomm SDM660 |
| MEMORY | 4 Go RAM | 64 Go Flash | Up to 64 Go via MicroSD slot. |
| DIMENSIONS & WEIGHT | HF ASK 210 mm x 79 mm x 17.2/28 mm (LxWxD) | 312 grams including battery HF ASK RCTIF | CEN/TS 210 mm x 79 mm x 17.2/28 mm (LxWxD) | 312 grams including battery HF | LF | BT HID-CK 210 mm x 79 mm x 17.2/28 mm (LxWxD) | 310 grams including battery |
| SCREEN | 5.0’’ HD screen (1280×720) | Capacitive touch panel |
| EXTERNAL PORTS | 1 Micro SD slot | 2 Nano SIM/USIM slots (ISO7816) | 1 USB 3.0 Type C | 2 Pogo Pins for Charging | Speaker | 1 Microphone | 1 Receiver | 1 Power Key | 1 Volume Key Up & Down | 3 Programmable Keys | Gyroscope | 1 e-Compass | 1 Light Sensor | 1 Accelerator |
| BATTERY | 3.85V | 4000 mAh exchangeable battery | Support QC3.0 Quick Charge |
| IP SEALING | IP67 |
| TEMPERATURES & HUMIDITY | Operating Temperature: Battery in charging mode > 0°C to +45°C | Battery in discharging mode > -20°C to +50°C | Storage Temperature: -20°C to +50°C | Humidity: 5% to 85% (non-condensing) |
| DROPS | Multiple drops from 1.2m | Compliant with MIL-STD-810G |
| BLUETOOTH | Bluetooth 5.1 |
| WLAN | WiFi (2.4 GHz – 5 GHz) | 802.11 a/b/g/n/ac |
| WWAN |
|
| INTEGRATED GPS | GPS | A-GPS | GLONASS | BeiDou | GALILEO |
