Lightweight ID tablets designed for true handheld applications
Our biometric ID tablets dedicated to Enrollment, Verification, Control, Identification
One unique platform, Two devices.
Access to all mobile biometrics needs (Fingerprint, Face, Iris and Document capture – 1:1 authentication, 1:N verification).
MULTIPLE
Keypoints
Lightweighted
The one and only tablet on the market that weighs less than 1kgs.
Security
High security level for captured and/or transmitted data.
Quality & flexibility
Built for harsh conditions & multiconfiguration device
Very high capacity battery
12.600 mAh battery to manage one-full working day
TECHNICAL
Specifications
IDENTIFICATION MODULES
PERFORMANCE
PHYSICAL CHARACTERISTICS
WIRELESS COMMUNICATIONS
IDENTIFICATION MODULES
| FINGERPRINT SCANNER | Optical or LES technology FAP20 or 50 | 500ppi | 256 grayscale dynamic range FBI Appendix-F certified, mobile ID, PIV, IQS FAP50, GSA FIPS 2001 |
| IRIS CAMERAS | Dual IR LED SFH4787S Camera resolution 2.4MP (IMX132) – IR bandpass filter |
| CAMERAS | Front camera: 8MP Fixed focus (IMX219) Rear camera: 13MP Auto focus (OV13850) – Dual Flash Light |
| SECURE ELEMENTS | Contactless card reader with integrated secure element from NXP (PN80T:PN553 + P73N2M0) Slot for external key integration |
PERFORMANCE
| OPERATING SYSTEM | Android 9 Compiled and signed by Coppernic in France |
| PROCESSOR | Processor Octa-Core SDM450 @ 1.8GHz 64-Bit architecture |
| MEMORY | 2GB RAM DDR3 + 16 GB Flash eMMC Memory expansion – MicroSD slot– T-Flash: Up to 256GB |
PHYSICAL CHARACTERISTICS
| DIMENSIONS & WEIGHT | FAP20: 288 mm x 147 mm x 25 mm | 785 grams — FAP50: 288 mm x 147 mm x 25 mm | 935 grams |
| DISPLAY & TOUCH PANEL | 7’’ TFT LCD | 1280×800 HD | 400 cd/m² | Corning Glass | Touch/Panel Glass: 0.7mm | Capacitive 5 Points Multi Touch |
| EXTERNAL PLUGS | USB type C for service port | USB type A host connector Audio Jack: Headset with Microphone |
| BATTERY | 12 600 MAH Removable battery pack Quick-charge with 12V 2.5A charger |
WIRELESS COMMUNICATIONS
| BLUETOOTH | Bluetooth LE 4.0 |
| WLAN | WiFi 802.11 a/b/g/n/ac – Direct – HotSpot |
| WWAN | 2G bands: GSM(850), EGSM(900), DCS(1800), PCS(1900) 3G bands: WCDMA Band 1,2,5,8 4G bands: LTE-FDD Band 1, 3, 7, 20, 28 A&B LTE-TDD Band 40 |
| INTEGRATED GPS | GPS | A-GPS | GLONASS | BeiDou (active antenna) |
